VW Transporter T5 T6 MP5 Monitor Car Parking Reverse Camera Kit
VW Transporter T5 T6 MP5 Monitor Car Parking Reverse Camera Kit
Couldn't load pickup availability
7inch Touch Screen Monitor Car Parking Rear View Camera Kit
HD reversing camera with 170° wide angle view. It provides security and high-quality image. Video displays on car DVD player, monitor etc.
Reverse cameras are small, wide-angle cameras mounted in the rear of a vehicle, and connected either to the infotainment screen on the instrument panel, or a small monitor in the rear-view mirror itself. When the driver starts reversing, the camera screen automatically appears to show the rear of the car.
Fitment: |
|
Camera Features:
- Effective Pixel: 720 x 580
- Resolution: 420 TV lines
- Lens Angle: 170 degrees
- Water-proof: IP67
- Power Supply: DC 12V
- Image Sensor: CCD
- Operating Temperature: -20 to + 80°C
- Storage Temperature: -40 to + 100°C
- Waterproof, shockproof, high temperature, high humidity
Monitor Features:
- Display resolution: 1024x600
- Screen size: 7 inches HD
- Type Portable: Car MP5
- System: Allwinner melis system
- Software Solutions: F133
- Radio transmitter frequency: FM 87.5 ~ 108.0MHz
- Radio transmitter IC: AB5301B
- Power amplifier IC: CS8571E
- Output power built-in: 1W speaker
- Working voltage: 12~24V
- Working temperature: -10~60 ℃
- Bluetooth Version: Version 5.0 (default name: CarPlay)
- Wi-Fi frequency: 2.4G/5G dual frequency It is only used to connect car play and
- Android auto)
Performance parameters
CPU: F133
Running memory: 1Gbit DRAM
USB interface: USB 2.0
TF card: support
Audio format: MP3/AAC/APE/OGG/M4A/RA/WAV
Video format: H263/h264/h265/DivX hd/avi/flv/mkv/mpeg4/MP4/WMV9/vc/asf/ts/qt
Image format: JPEG/PNG/BMP/GIF/TIFF
Language: English, Chinese, Spanish, Portuguese, Russian, German, French, Polish, Turkish, Arabic, Hebrew, Italian, Czech, Japanese
Parking rear-view priority: the monitor will start up automatically and synchronously display the video from reversing camera when you're reversing your van.
The brightness, contrast, and colour are adjustable through the buttons at the front of the monitor.
Package Included:
- 1 x Reversing Camera
- 1 x 7inch Touch Screen Monitor
- 1 x Extension Cable 2m
- 1 x Suction Cup Bracket
- 1x Remote Control
- Drill bit
